Description
- General Specification.Door curtain:
Twin walled foam filled aluminium profile 52mm x 12mm
Extruded heavy duty bottom rail.
Rubber weather seal fitted to base of curtain.Locking:
Sprung loaded auto locks fitted to every door.Guide rails:
66mm heavy duty extruded channels with brush pile and neoprene lining.Motor and box assembly:
Driven by Euro 40nm tube motor.
Internal crank handle for use in a power cut.
205mm aluminium full box cover. Encases curtain to further reduce drafts and leaves etc.Control systems:
Remote control with up, down and stop buttons.
2 remote fobs supplied as standard.
Inbuilt automatic LED courtesy light.
Description
Built for wider UK garages, the Hurricane H77 uses a 77mm double-skinned aluminium slat curtain with a polyurethane insulated core for improved thermal and acoustic performance.
The curtain rolls neatly into a top enclosure, with brush-guided side channels and a weather-sealed bottom rail to reduce drafts.
Electric operation comes as standard with remote controls, with optional keypad and smart phone control.
Safety edge protection and manual override options are available for extra peace of mind during power cuts.
Additional information
| Fit Type | Internal Face Fix, External Face Fix, Reveal Fix, Combination Fix |
|---|---|
| Colours | Standard, Wood Grain |
| Vision Slats | None, 1 Row, 2 Rows, Custom |
| Box (Hood) | Full Box, Open Roll (Internal Only) |
| Box Shape | 45 Degree, 90 Degree, Ropuinded |
| Size Guide | 70mm, 80mm, 150mm |
| Extra Remotes | 0, 1, 2, 3, 4 |
| Keypad | Yes, No |
| Wall Switch | Yes, No |
| Safety Pack | Standard Safety Edge, Enhanced (Edge & Beams) |
| Manual Override | None, Internal Override, External Emergency Override |
